Key Features:
Economical and practical with comprehensive functionality – The unit features a simple design and low cost; supports full configuration of temperature, delay, channel count, IP settings, and more, meeting the protection needs of various small equipment with high cost-performance ratio.
Easy installation and rapid deployment – Ready to use out of the box with no additional components required; supports multiple mounting methods including side-mounted and floor-standing; clear cutout specifications and simple wiring ensure short construction cycles and fast on-site deployment.
Compact and flexible with strong adaptability – Small footprint and space-saving design allow flexible installation next to equipment or in confined spaces; installed in close proximity to the protected equipment without interfering with production operations, suitable for a wide range of small equipment protection scenarios.
Extremely simple operation, accessible to all – Clearly arranged buttons and intuitive menu settings support one-click configuration of temperature, delay, channel count, and IP address; no professional training required, allowing ordinary personnel to quickly master operation and parameter settings.
Self-maintenance and worry-free after-sales support – High system stability with clear and straightforward fault self-diagnostics; users can independently perform routine inspections, parameter adjustments, and basic maintenance; 24/7 dedicated service hotline with fast response, and a streamlined after-sales process with low costs.
Application Areas:
High-end precision equipment, semiconductor manufacturing equipment, data centers, communication base stations, archives, financial centers, and other manned areas housing valuable equipment. It is currently the most widely used clean agent.
Product Name | Heptafluoropropane Fire Extinguishing Device (AFM) | |||
Model | AFM-3A | AMN-10A | AMN-20A | AMN-30A |
Extinguishing Agent Weight | 3.0 kg | 10.0KG | 20.0KG | 30.0KG |
Main Body Weight | 15.0 kg | 50.0KG | 100.0KG | 150.0KG |
Protectable Volume | 3.5 m³ | 10.0m³ | 20.0m³ | 30.0m³ |
External Dimensions | 205*195*450 (mm) - Excluding height of audio-visual alarm | |||
Material & Coating | Stainless Steel 304 with Melamine Paint Finish | |||
Operating Temperature Range | -10℃ ~ 50℃ | |||
Input Voltage | DC 24V, 10A | |||
Temperature Sensor Capacity | 1 ~ 3 units | |||
External Sensor Input Capacity | 1 channel Normally Open (NO) input | |||
Operating Power | 10 W | |||
Maximum Power | 50 W | |||
Fault Output | One set of DC 24V | |||
Alarm Indicator | Green light for normal operation; Red light and audible alarm for abnormal operation | |||
Standard Buttons | Power Switch Button, Fire Extinguishing Button | |||
Liquid Level Indicator | Standard: Illuminates when extinguishing agent is insufficient | |||
Remote Extinguishing Button | Optional | |||
Agent Characteristics | 1. Widely used clean agent for occupied spaces with valuable equipment, such as high-end precision instruments, semiconductor facilities, data centers, communication base stations, archives, and financial centers. | |||
